Denon PMA-1600NE Amplifier
Denon is one of the rare audio brands that continue to actively develop Hi-Fi components and accumulate, refine, and pass down Hi-Fi audio technologies. The performance of the PMA-1600NE goes well beyond that of Denon’s previous PMA-1500 series. With its ultimate built-quality, unique Denon technologies and state-of-the-art connectivity, the PMA-1600NE truly is a masterpiece of sound technology. Thanks to the rear USB-B input and embedded high quality D/A converter, the PMA plays high resolution files up to 384kHz/32bit and DSD up to 11.2MHz from a computer in impeccable sonic quality. For the best performance from analogue inputs, the PMA-1600NE features an Analog Mode which allows to switch off all unutilized sections like the digital input circuitry or the low noise display for an unaltered audio reproduction.
Advanced Ultra High Current MOS Single Push-Pull Circuit
The amplifier features Advanced UHC (Ultra High Current)-MOS technology that utilizes a minimum number of high-current amplifier elements to balance advanced speaker drive capabilities and improved sound quality.
The chassis constructed with 1.0mm thick steel plates protects the signal circuits from external vibration and eliminates the adverse effects of mutual interference among the circuits. The power section has been positioned in the center of the PMA-1600NE. With heat sinks on both sides, this construction of well-balanced mass is in an ideal location to prevent unwanted vibration from affecting sound quality.
Digital isolator and Analog Mode
The PMA-1600NE is equipped with a high-speed digital isolator to eliminate adverse influences on sound quality caused by high-frequency noise from a USB-connected computer or from the PMA-1600NE’s digital inputs. Since data is transferred magnetically via coils embedded in an IC chip, the input and output sides are electrically isolated. By isolating the signal line between digital audio circuitry and the D/A converter, adverse influences of high-frequency noise on analogue audio circuitry after the D/A converter are eliminated. The PMA-1600NE also adopted a dedicated secondary winding in power transformer for the digital circuitry to shut out noise from the power source. During analogue audio playback, the Analog Mode can be used to turn off power to the dedicated digital power source and completely stop operation of the digital input circuitry to avoid any high frequency influence to the analogue section.
System remote controller and clear view front display:
The PMA-1600NE comes with a system remote control unit that can also operate the DCD-1600NE and other Denon CD players. The low noise FL display on the product front panel gives source and sample rate indication.
Output power 8 Ohm (20 Hz – 20 kHz, T.H.D. 0.07%): 70 W
Output power 4 Ohm (1 kHz, T.H.D. 0.7%): 140 W
Total Harmonic Distortion: 0.01%
Input Sensitivity: MM: 2.5 mV / 47 kohm
Signal to Noise Ratio: MM/MC: 89 dB / 74 dB
Input Sensitivity: High level: 125 mV / 47 kohms
Signal to Noise Ratio: High level: 108dB
Treble Control: ± 8 dB at 10 kHz
Ovládání bassů: ± 8 dB at 100 Hz
Audio Inputs: 4
Phono Input: MM / MC
Audio Outputs: 1
Gold plated Cinch
Number of terminals: 2
Remote Control Bus in / out
Digital in: USB-B / optical / coaxial
