Description
Denon PMA-60 Amplifier:
Digital Integrated Stereo Amplifier:
The PMA-60 amplifier delivers true Denon sound, with outstanding performance despite its compact size. And it does so using Denon technology developed over many years, such as the Advanced AL32 audio processing it uses to turn digital data into beautiful music. With analogue and digital connectivity as well as Bluetooth®, audio streaming from your computer or a portable device is a piece of cake. And if you’re keen on high-resolution audio, this amp will be your perfect choice because of its USB-B input. Its 50W per channel output makes it suitable for a wide range of speaker types.
Fully digital processing
Since DDFA is a digital input type Class D amplifier, when playing back a digital source, interpolation processing by “Advanced AL32 PP” technology, volume adjustment, amplification, and feedback management is all undertaken in the digital domain.
> Advanced AL32 Processing Plus is compatible with PCM signals only.
Bespoke Hi-Fi components taken from Denon’s high-end “NE series”
We have employed a number of audio electrolytic capacitors, resistors, film capacitors that are also used in the “NE series”, a new generation of Denon’s renowned Hi-Fi components. These optimum parts were selected by our lead sound engineer only after repeated auditions. To further refine sound quality.
Powerful and detailed sound
The advanced amplifier section incorporates Qualcomm DDFA® technology for an amazing sound from a compact form factor. The output stage circuit has a discrete construction which realizes higher Signal-to-Noise-ratio and lower distortion compared to conventional class D amplifiers.
Precise digital volume control
Volume can be precisely adjusted in 1dB steps. Since processing is all undertaken in the digital domain, it is possible to completely eliminate gang errors and crosstalk which cause volume difference between the left and right channels.
Specifications:
Output power 8 Ohm (20 Hz – 20 kHz, T.H.D. 0.07%): 25W (1kHz)
Output power 4 Ohm (1 kHz, T.H.D. 0.7%): 50 W
Total Harmonic Distortion: 0.00%
Input Sensitivity: High level: 70 mV
Signal to Noise Ratio: High level: 110dB
Treble Control: ± 8 dB at 12 kHz
Ovládání bassů: ± 8 dB at 100 Hz
Audio Inputs: 1
Digital in: USB-B / optical / coaxial /
Pre-out (Subwoofer) / Main-in
Number of terminals: 2
Headphone Out
Headphone Gain Control (low / mid / high)
